SHBD Metal offers CNC milling, turning, EDM, and grinding services for tight-tolerance metal and plastic components. Tolerances to ±0.01 mm available on qualified projects. Parts shipped in as little as 1 day.
STEP | STP | SLDPRT | IPT | PRT | SAT files · All uploads are secure and confidential.
Precision machining uses advanced CNC technology to produce highly accurate parts for aerospace, medical devices, and electronics. This process ensures every component meets exact specifications for size, shape, and function. CNC precision machining is essential for detailed and complex designs beyond conventional machining capabilities.
With SHBD Metal's precision CNC services, industries achieve tight tolerances and high precision, ensuring each part functions perfectly in its intended application. From small-scale prototypes to large-volume production, we deliver durable and dependable components.
Get Quote
From wire EDM to multi-axis milling, we offer a comprehensive range of precision machining capabilities.
SHBD Metal's wire EDM efficiently creates both simple and intricate shapes. Ideal for parts requiring high precision, this contact-free method produces minimal burrs and excels with metals like steel and titanium.
| Capability | Details/Specifications |
|---|---|
| Material Compatibility | Stainless Steel, Titanium, Aluminum, Tool Steel, Copper |
| Tolerance | ± 0.0001 inches (0.0025 mm) or better |
| Maximum Workpiece Size | Length: 400 mm | Width: 300 mm | Height: 200 mm |
| Cutting Speed | Up to 300 mm²/min |
| Surface Finish | As fine as Ra 0.2 µm |
| Maximum Cutting Thickness | Up to 300 mm |
| Wire Diameter Range | 0.1 mm to 0.3 mm |
Mirror EDM delivers mirror-reflective surfaces through high-precision machining. Capable of producing intricate shapes with tight tolerances, it excels on hard materials where conventional tools struggle.
| Capability | Details/Specifications |
|---|---|
| Material Compatibility | Stainless Steel, Titanium, Aluminum, Tool Steel, Copper |
| Surface Finish | Achievable down to Ra 0.05 µm or better |
| Tolerance | ± 0.00005 inches (0.0013 mm) or better |
| Maximum Workpiece Size | Length: 400 mm | Width: 300 mm | Height: 200 mm |
| Maximum Cutting Thickness | Up to 250 mm |
SHBD Metal's precision grinding delivers exceptional surface finishes and tight tolerances. Our surface, cylindrical, and centerless grinding capabilities handle everything from simple flats to complex geometries.
| Capability | Details/Specifications |
|---|---|
| Material Compatibility | Stainless Steel, Aluminum, Tool Steel, Copper, Ceramics, Carbides |
| Grinding Methods | Surface Grinding, Cylindrical Grinding, Centerless Grinding, Internal Grinding |
| Tolerance | ± 0.0001 inches (0.0025 mm) or better |
| Maximum Workpiece Size | Length: 600 mm | Width: 250 mm | Diameter: 200 mm |
| Surface Finish | Achievable down to Ra 0.1 µm or better |
SHBD Metal's advanced CNC turning delivers unmatched accuracy and repeatability for machine parts and prototypes. Our diverse turning centers support varied applications, ensuring consistent precision across batches.
| Capability | Details/Specifications |
|---|---|
| Material Compatibility | Stainless Steel, Aluminum, Tool Steel, Copper, Brass, Titanium, Plastics |
| Turning Operations | External & Internal Turning, Facing, Taper Turning, Boring, Drilling, Threading |
| Tolerance | ± 0.0005 inches (0.0127 mm) or better |
| Max Workpiece Diameter | 508 mm |
| Max Workpiece Length | 1524 mm |
| Axis | 2-axis, 3-axis, multi-axis turning capability |
SHBD Metal's multi-axis milling machines deliver CNC parts with tight tolerances and precise dimensions. Compatible with a broad material range from metals to composites, our CNC milling ensures efficient production with rapid turnaround.
| Capability | Details/Specifications |
|---|---|
| Material Compatibility | Stainless Steel, Aluminum, Tool Steel, Copper, Brass, Titanium, Plastics |
| Milling Operations | Face Milling, Profile Milling, Pocket Milling, Complex Surface Milling, Drilling, Boring |
| Tolerance | ± 0.0005 inches (0.0127 mm) or better |
| Max Workpiece Size | X: 1016 mm | Y: 508 mm | Z: 635 mm |
| Axis | 3-axis, 4-axis, 5-axis milling capability |
From rapid prototyping to high-volume production, we deliver precision-machined parts at every stage of your product development.
Leverage our robust manufacturing capabilities for swift, high-quality prototype delivery. Using the latest technology, we ensure rapid and accurate production, accelerating your path from testing to market.
Learn MoreSHBD Metal is equipped to handle large-scale production orders. We efficiently produce large quantities of CNC precision-machined parts without compromising quality or accuracy.
Learn MoreOur precision machining capabilities deliver tight tolerances across all processes. Below are the typical and best achievable tolerances for each service.
| Process | Typical Tolerance (mm) | Best Possible Tolerance (mm) | Notes |
|---|---|---|---|
| EDM (Electrical Discharge Machining) | ±0.015 | ±0.005 | Tolerance can be affected by electrode wear |
| Grinding | ±0.005 | ±0.001 | Surface finish is typically smoother with grinding |
| CNC Turning | ±0.025 | ±0.010 | Finish can impact tolerance |
| CNC Milling | ±0.025 | ±0.005 | Precision can vary based on tool type and material |
Over the years, we have successfully tackled various complex precision machining challenges for clients across multiple industries.
Custom CNC-machined aluminum brackets and flanges for premium motorsport display installations, delivered to exacting visual and structural standards.
Read Case Study →
CNC-machined actuator brackets, noise-dampening chassis mounts, and corrosion-resistant steel frames for dynamic seating platforms.
Read Case Study →We provide a wide range of materials and superior surface finishes that enhance part durability and aesthetics.
This finish leaves the surface directly from the CNC machine, providing a cost-effective option with visible tool marks.
This process smooths the surface by removing tool marks, resulting in a refined finish with varying levels of gloss and texture.
This process creates a uniform, matte texture by propelling fine abrasive particles onto the surface, removing imperfections and tool marks.
A protective and aesthetic coating is applied to the surface, offering a smooth, uniform finish with customizable colors and textures.
A durable, wear-resistant finish applied electrostatically and cured under heat, providing a uniform, protective coating in various colors.
An electrochemical process that enhances surface durability, corrosion resistance, and appearance, available in various colors with a smooth or matte finish.
An electrostatically applied coating that provides a uniform, corrosion-resistant finish with excellent adhesion, commonly used for protective and aesthetic purposes.
A protective and decorative coating that enhances corrosion resistance, wear resistance, and surface hardness while providing a smooth, metallic finish.
